The Ergox EA-KBT-09 adds a sliding, height-adjustable keyboard and mouse platform beneath a desk without drilling. Padded clamps secure the tray to a suitable desktop and allow it to be removed later.
- 670 x 240 mm keyboard and mouse platform
- 5 kg weight capacity
- Stepless adjustment across an 81 mm height range
- 242 mm sliding travel for storage beneath the desk
- Fits desktops up to 35 mm thick
Compatibility and installation
Before ordering, allow at least 828 mm of clear width and 402 mm of clear depth beneath the desk. Check for frames, crossbars, drawers and cable hardware that could obstruct the clamps or sliding tracks.
Watch the setup video in the product gallery.
Technical specifications
| Model | EA-KBT-09 |
|---|---|
| Product type | Clamp-on under-desk keyboard tray |
| Material | Steel, plastic and particle board |
| Platform size | 670 x 240 mm |
| Overall dimensions | 836 x 644 x 142–162 mm |
| Weight capacity | 5 kg |
| Height range | 81 mm |
| Track travel | 242 mm |
| Maximum desktop thickness | 35 mm |
| Minimum installation clearance | 828 mm wide x 402 mm deep |
| Warranty | 2 years |
Frequently asked questions
Do I need to drill into the desk?
No. The EA-KBT-09 uses padded desk clamps and does not require screw holes in the desktop.
How thick can the desktop be?
The clamps fit desktops up to 35 mm thick.
How much clear space is required?
Allow at least 828 mm of clear width and 402 mm of clear depth beneath the desk, without frame or drawer obstructions.
Will it hold a keyboard and mouse?
The platform measures 670 x 240 mm and supports up to 5 kg. Confirm that your keyboard and mouse fit within those dimensions.
Can the tray slide under the desk?
Yes. The track provides 242 mm of sliding travel so the platform can be stored beneath a compatible desk.
